programmeren Baofeng uv5r

How to manually program a simplex channel

• Step 1. Press [VFO/MR] and enter Frequency Mode.
• Step 2. Press [A/B] and choose the A Side (upper display).
  The A side must be used to program channels into the radio. Programming data entered on the B Side (lower display) will not be saved.
• Step 3. Press [BAND] for the frequency band.
  Toggle [BAND] to choose 136 MHz (VHF) or 470 MHz (UHF).
  If the incorrect band is chosen for the frequency entered in Step 5, the radio will cancel the operation.
• Step 4. Disable TDR (Dual Watch/Dual Standby).
  Press [MENU] 7 [MENU] [press up/down arrow keys] OFF [MENU] [EXIT]
  It is highly advised to turn TDR off when programming directly from the radio.
• Step 5. Enter the frequency.
  Use the keypad to enter the frequency into the radio.
• Step 6. optional – Enter the transmit CTCSS/DCS code.
  • CTCSS – [MENU] 13 [MENU] [enter/choose code XXXX] [MENU] [EXIT]
  • DCS – [MENU] 12 [MENU] [choose code XXXXX] [MENU] [EXIT]
• Step 7. Assign the frequency to a channel.
  [MENU] 27 [MENU] [enter channel number XXX] [MENU] [EXIT]

How to manually program a repeater channel

• Step 1. Press [VFO/MR] and enter Frequency Mode.
• Step 2. Press [A/B] and choose the A Side (upper display).
  Like the simplex channels, the A side must be used to program the repeater channels into the radio. Programming data entered on the B Side (lower display) will not be saved.
• Step 3. Press [BAND] for the frequency band
  Toggle [BAND] to choose 136 MHz (VHF) or 470 MHz (UHF).
  If the incorrect band is chosen for the frequency entered in Step 6, the radio will cancel the operation.
• Step 4. optional – Clear any CTCSS/DCS codes previously assigned to the channel.
  If no previous codes exist or when setting up the channel for the first time and no codes are needed, set the menu items listed below to OFF.
  • RX DCS – [MENU] 10 [MENU] [enter 0 (OFF)] [MENU] [EXIT]
  • RX CTCSS – [MENU] 11 [MENU] [enter 0 (OFF)] [MENU] [EXIT]
  • TX DCS – [MENU] 12 [MENU] [enter 0 (OFF)] [MENU] [EXIT]
  • TX CTCSS – [MENU] 13 [MENU] [enter 0 (OFF)] [MENU] [EXIT]
• Step 5. Disable TDR (DualWatch/Dual Standby).
  Press [MENU] 7 [MENU] [press up/down arrow keys] OFF [MENU] [EXIT]
  It is highly advised to turn TDR off when programming directly from the radio.
• Step 6. optional – Delete any existing data on the channel to program.
  Skip this step when setting up the channel for the first time. Press [MENU] 28 [press up/down arrow keys to choose channel number] [MENU] [EXIT]
  It is highly advised to turn TDR off when programming directly from the radio.
• Step 7. Enter the frequency.
  Use the keypad to enter the frequency into the radio.
• Step 8. Input the repeater frequency offset.
  Press [MENU] 26 [MENU] [enter the offset for 2 meter or 70 cm repeater] [MENU] [EXIT]
• Step 9. Enter the Transmit Frequency Shift.
  Press [MENU] 25 [MENU] [enter 1 for positive shift or 2 for negative shift] [MENU][EXIT]
• Step 10. optional – Enter the transmit CTCSS/DCS code.
  • CTCSS – [MENU] 13 [MENU] [enter/choose code XXXX] [MENU] [EXIT]
  • DCS – [MENU] 12 [MENU] [choose code XXXXX] [MENU] [EXIT]
• Step 11. Enter the repeater output frequency.
  Use the keypad to enter the frequency into the radio.
• Step 12. Assign the receive frequency to the same channel in Step 6.
  [MENU] 27 [MENU] [enter channel number XXX] [MENU] [EXIT]
• Step 13. Press the [*Scan] button to activate Reverse Mode and display the transmit frequency.
• Step 14. Assign the transmit frequency to the channel.
  Press [MENU] 27 [MENU] [enter the same memory channel in step 27] [MENU] [EXIT]
• Step 15. Press the [*Scan] button to exit .
